Guild CV1 Sunburst


The Guild CV-1 Acoustic Guitar has a vintage body, accented by a solid spruce top and solid Indian rosewood back and sides with a laquer finish. Patented Guild Neck Block System, bone nut and saddle, ivoroid bindings, Madagascar rosewood fingerboard and bridge, pearl logo and new G shield, plus abalone dot inlays compltte this stunning Guild guitar. This is a 2006 – 2008 Guild Tacoma CV-1. This guitar has some unique features. It’s based on traditional acoustic shapes, but the neck joint uses a graphite neck block and bolt system. Fender had apparently applied for patents on this system, but they weren’t granted. Variations on this type of bolt-together arrangement (except for the graphite block) is now found on many quality guitars, including Taylors, Collings, and LaSiDo. Many independent builders also use versions of the bolt-together joint.


The reason is that nearly all acoustics of a certain age are going to require a major piece of work called a neck reset. This need arises because over time, string tension effectively lowers the neck angle, and the action goes up to a point where the saddle can’t be lowered enough. On guitars with conventional glued dovetail or tenon joints, this work is expensive and is done by techs with high skill levels; on some instruments, some finish work is also needed. With the bolt-secured arrangements, the work can be done in a few hours with no finish work required. In short, this is a really good idea with lots of practical benefits and no significant tonal downside.


The tone of this instrument is rich, clear and transparent, with deep lower mids and a sparkling upper range. A real beauty, both in form and function..

Body style
Top
Bracing
Back
Sides
Bridge
Neck
Fretboard
Width at nut
No. Of frets
Scale length
Hardware
Machine heads
Finish
Unique features











Case

Specifications


F-40
Spruce
Spruce
Indian rosewood
Indian rosewood
Madagascar rosewood
Mahogany (bolt-on)
Madagascar rosewood (12" radius)
1-3/4"
21
25-1/2"
Nickel
Gotoh 500 open-back tuners
High gloss sunburst (nitro-cellulose lacquer)
Patented graphite neck-block bolt-on neck system, dual locked graphite neck reinforcement tubes, spruce braced top, abalone dot position inlays, Madagascar rosewood bridge pins with abalone dots, bone nut, streamlined compensated bone saddle, multi-lam ivoroid bindings and end-strip with red and black accent lines, contemporary guild rosette of Madagascar rosewood, ivoroid and red and black accent lines, tortiose shell pickguard, factory installed forward strap button with internally braced support, vintage script mother-of-pearl guild headstock logo, contemporary mother-of-pearl guild headstock shield
Includes deluxe hardshell guitar case

For more information or if you have any questions please feel free to contact us.

Contact us

We are also happy to provide high resolution pictures to anyone interested in purchasing a guitar.
